Power chucks with through-hole

Automated series production of turned parts and machining bars

RÖHM power chucks with through-hole are used successfully both for machining bars and pipes as well as for machining flange-type workpieces. The proven wedge system allows maximum clamping forces with maximum clamping precision at the same time. The rigidity of the power chucks, which contributes to this, is achieved with a sturdy chuck construction.

1: Easy spindle adaption for cylindrical center mount

2: High load capacity by proven wedge-hook system

3: Different types of gearing for different jaw variants

4: Large through-hole for hollow and partly-hollow clamping


DURO-A

Premium power chuck with large through-hole, constant clamping force for more than 500,000 cycles for the highest clamping forces and speeds.

More



KFD-HS, 2-jaw

Premium power chuck with very large through-hole for the highest clamping forces and speeds

Details in eShop

KFD-HS, 3-jaw

Premium power chuck with very large through-hole for the highest clamping forces and speeds

Details in eShop

KFG

Power-operated angle lever chuck for large jaw stroke for flexible use with large through-hole

Details in eShop

PKF

Air-operated wedge hook chuck for very high concentricity and clamping repeatability within 0.003 mm

Details in eShop
