THE F-SENSO 2

For measurement of clamping force on lathe chucks.

The F-Senso 2 is a modular system for measuring the clamping force of clamping devices. It is used in workshops, in manufacturing plants or in laboratories for checking the clamping force before and after maintenance or repair work on the clamping device, and for checking the clamping system in the machine tool. The F-Senso 2 is made up of the Senso module and a measuring head, which varies depending on the clamping device. The measured results are displayed on the tablet PC supplied.

The F-Senso 2 is available with the F-Senso chuck module measuring head to measure the clamping force in manual lathe chucks, power chucks, and vices. The F-Senso HSK module enables the clamping force of clamping sets with hollow shaft cone to be measured.

An F-Senso 2 complete set in sturdy plastic case consists of the F-Senso 2 module, a measuring head, and a tablet PC including visualization and archiving software. Additional measuring heads are available as additional sets, also in a sturdy plastic case. The F-Senso 2 replaces the F-Senso chuck and F-Senso spindle clamping force measurement devices.

DESIGNED FOR

Vices, manual lathe and power chucks, HSK clamping sets in manufacturing plants, repair workshops or laboratories.

APPLICATION

Measurement and checking of clamping force,including during rotation.

BENEFITS

  • Modular system, one F-Senso 2 module for all measuring heads
  • Measurement static or at speed
  • Robust design
  • Wireless transmission of measurement data
  • Comprehensive software for visualization, archiving, management

WHY IT’S A WISE INVESTMENT

F-SENSO 2 MODULE CHUCK

  • 32 mm - 120 mm clamping diameter
  • Up to 225 kN (size 65, 3 jaws)

F-SENSO 2 MODULE HSK

  • HSK 40, 50, 63, 100
  • Up to 90 kN (HSK 100)

1.Large hard-shell case with foam inserts

2. Small case with foam inserts for accessories

3. Senso module

4. Power supply unit for Senso module and USB cable

5. Mounting key

6. Tablet PC with keyboard

7. Power supply unit

8. Magnet for speed measurement

9. F-Senso 2 modules (depending on version)

Product information
